Product Details

Container

Max Container Volume  Itr

2

Max Neck Diameter  mm

50

Max Container diameter  mm

110

Max Container Height  mm

320

Technical Parameters:



DY-2000

DY-2000S

Molding

Clamping Force  kg

18000

14000

Clamping Stroke  mm

125

125

Stretching strok  mm

450

450

Bottom Stroke  mm

40/70

40/70

Cavity Spacing  mm

120

120

Number of Cavity  Cavities

2

2

Carriage Unit pcs

66

66

Theoretical Output

  bph

1800-2200

1800-2200

Electrical System

Total Power  kw

26

26

Heating Power  kw

16x1.5KW=24

16x1.5KW=24

Number of Lamp Layers  Layers

8

8

Air System

Operating Pressure  kg/cm²

7-9

7-9

Low Pressure Air Consumpt Itr/min

1600

1600

Blowing Pressure  kg/cm²

20-30

20-30

High Pressure Air Consumpt Itr/min

1600

1600

Chiller

Operating Pressure kg/cm²

2-4

2-4

Temperature Range ℃

10-12

10-12

Consumption  kcal/hr

2000

2000

Flow Rate  Itr/min

130

130

Main Machine

Main machine dimensions mm(L*W*H)

1950 x1850x2100

1950x1850x2100

Main Machine Weight  kg

1950

1950

Preform Loader

Preform Loader Dimensions  mm(L*W*H)

2150x1450x2450

\

Preform Loader Weight  kg

450

\
