Full Automatic Blow Molding Machine (2 Cavity)-10L

Full Automatic Blow Molding Machine (2 Cavity)-10L

Email: sales@dianyamachine.com

Product Details

Container

Max Container Volume Itr

11

Max, Neck Diameter   mm

65

Max Container Diameter  mm

220

Max Container Height mm

430

Technical Parameters:



DY-A10L-2

Molding

Clamping Force  kg

32000

Clamping Stroke  mm

260

Stretching strok  mm

450

Bottom Stroke  mm

50/70

Cavity Spacing  mm

250

Number of Cavity  Cavities

2

Carriage Unit pcs

63

Theoretical Output

bph

800-1200

Electrical System

Total Power  kw

78

Heating Power  kw

48x1.5KW=72

Number of Lamp Layers  Layers

12

Air System

Operating Pressure  kg/cm²

7-9

Low Pressure Air Consumpt Itr/min

3000

Blowing Pressure  kg/cm²

30-40

High Pressure Air Consumpt Itr/min

6000

Chiller

Operating Pressure kg/cm²

2-4

Temperature Range ℃

10-12

Consumption  kcal/hr

3000

Flow Rate  Itr/min

500

Main Machine

Main machine dimensions mm(L*W*H)

4200 x2150x2200

Main Machine Weight  kg

4500

Preform Loader

Preform Loader Dimensions  mm(L*W*H)

2200 x1350x2650

Preform Loader Weight  kg

550
